Description
The bifacial 210W 12V solar panel offers an innovative solution to maximize energy yield by harnessing both direct sunlight on the front side and reflected light on the rear side. This dual-sided power generation can increase total energy output by up to 30%, making it ideal for installations on reflective surfaces such as snow, sand, or light-colored rooftops.
Double-glazed modules are ideal for various stationary solar systems such as balconies, gardens, carports, garage roofs, or self-sufficient island solutions. Choosing a suitable tilt angle is crucial for optimal use of the rear-side power, thus ensuring maximum efficiency and increased reliability.
Special Features
- Dual-glass design for enhanced durability and longevity
- Higher energy output by utilizing both direct and reflected sunlight
- High cell efficiency of 23.1%
- Improved temperature coefficient for stable power output in varying conditions
- 2 integrated bypass diodes – minimizing power loss during partial shading
- Tempered ESG solar glass with weather-resistant coating for superior durability
- Extra robust anodized aluminum frame for long-term stability
- 24 cm solar cable (4.0 mm²) with MC4 connectors
- TÜV certified according to IEC61215 & IEC61730 standards
- Plus tolerance guarantee (+ 3%), performance guarantee up to 10 years with 90% and up to 25 years with 80%
Technical Specifications
| Item number | 1170210 |
| EAN Code | 4260558576365 |
| Max. power(Pmax) | 210Wp |
| Max. voltage(Vmp) | 21.0V |
| Max. current (Imp) | 10.0A |
| Open circuit voltage (Voc) | 24.6V |
| Short circuit current (Isc) | 10.87A |
| Temperature coefficient of Voc | -0.36%/K |
| Temperature coefficient of Isc | 0.05%/K |
| Temperature coefficient of power | -0.44%/K |
| Normal operating cell temperature | 44+/-2°C |
| Operating temperature | -40 ~ +85°C |
| Max. System voltage | 1000V DC |
| Power tolerance | 0 ~ +3% |
| Junction Box | Waterproof IP65 |
| Bypass Diodes | 2 pcs |
| Solar Cells | Monocrystalline 36 (4 × 9) |
| Performance Warranty | 25 years |
| Module dimension | 1310 × 765 × 30 mm |
| Module weight | 12.5kg |
